Equipment list:
• 48" pit conveyor for ground level loading
• American Pulverizer 4800 ringmill (300HP)
• Under mill oscillator
• 48" outfeed conveyor 48" + 6 transfer and feed conveyors
• 150HP secondary vertical shredder
• 2 rare earth drum magnets
• 48" air knife
• 48" eddy current separator
Processes:
• Shredder Pickings,
• Shredder fines
• Palm transformers, etc.
Some cosmetic damage, but in good working condition
• Constructed in carbon steel
• With support grids
• Top screen discharge
• Aspirator with transition
• Two square mesh carbon steel screens with ball cleaners
• 2HP motor
Out of stock
• Overall Size 116”Lx55”Wx81”H
• Hopper capacity ≈ 60cu ft
• Hopper size 59”Lx50”Wx46”H
• Auger size 6”
• Motor 3hp 3phase
• Agitator motor 1/2hp 3 phase
• Belt is 18″x67″
• Magnet: 13”x12.5”
• Overall dims of the crossbelt: 72”x30”
• Overall dims of the stand: 45”x53”x75” Tall
• 1.5HP 3PH electric motor
Out of stock
Model SVE 800/ X2200
• 2.4kw(3hp) electric motor.
• Overall size: 55 wide by 126 long by 45” tall
• Screen Deck is 31” wide by 88” long
• Current finger screen is ½” rods spaced ½” apart.
Double Deck: $12,500
Single Deck: $11,500
• M.S Construction
• Fitted with suitable S.S.304 screens (specify mesh)
• Adjustable three plane motion
• Anti blinding PP rings
• Perforated sheet beneath the mesh
• Supported on steel base designed for floor mounting
• Vibrating assembly is isolated by a spring assembly
• Complete with 1.5 HP special vibrating totally enclosed motor 480V-60Hz 3Phase electric motor.
• Top and bottom eccentric weights and lead scale indicator with top dust cover.
• Overall Size 139”Lx62”Wx70”H
• Hopper capacity ≈ 85cu ft
• Hopper size 86”Lx62”Wx46”H
• Auger size 10”
• Motor 3hp 3phase
New Never used
• 60” single deck (35 mesh screen installed, will come with specified screen)
• 460V 1200 RPM 2.5HP Motor.
• Carbon steel base and lower table assembly, twelve (12) spring assemblies and a 2-1/2 horsepower 460 volt, 3 phase, 60 cycle, 1200 rpm, TENV motion generator.
Component Parts:
• One (1) 8” table frame of stainless-steel construction, including one (1) 6” x 8” discharge spout and one (1) standard clamp ring. One (1) 8” spacing frame of stainless-steel construction, including one (1) 6” x 8” discharge spout and one (1) standard clamp ring.
• One (1) Installed Screen: 35-Mesh Size
• One (1) 60” domed cover assembly of stainless-steel construction with an 8” charge port and 6” inspection opening, assembly to include FDA approved white neoprene cover for I/O, 60” tension ring with gasket and clamp ring assembly.
30″ x 60″ three deck Rotex screener
• Aluminum cover and screen frames.
• Automatic tension.
• Mild steel pan and box frame.
• 145 lbs upper, 45 lbs lower. 4 outlets.
• Motor: 2 hp, 208-230/460 volts.
Model: 403A-AL-MS
Serial: R360888
• Built in 2021
• Comes with 4 sets of knives/beds, 2 of them are brand new
• Comes with 3 table screens, 2 of which are brand new
• Overall Size 164”Lx60”Wx96”H
• Hopper capacity ≈ 108cu ft*
• Hopper size 96”Lx56”Wx61”H
• Auger size 9”
• Motor: 1hp 3phase Inverter duty
• Gearbox: Extreme torque SEW Gear Motor, Ratio 193:1, 9.1 RPM, Output 2.375″ Hollow Shaft, Mounting position M1, 1HP Motor, 460 VAC, 60 HZ, Output Torque 6530 lb-in, torque capacity 26,600 lb-in, S.F. 4.10
*Additional option to extend hopper36” taller to increase capacity from 108 to 220 cubic ft +$2,600.00
• Overall Size L” x60”Wx96”H
• Hopper capacity ≈ 175cu ft*
• Hopper size 156”Lx56”Wx61”H
• Auger size 9”
• Motor: 1hp 3phase Inverter duty
• Gearbox: Extreme torque SEW Gear Motor, Ratio 193:1, 9.1 RPM, Output 2.375″ Hollow Shaft, Mounting position M1, 1HP Motor, 460 VAC, 60 HZ, Output Torque 6530 lb-in, torque capacity 26,600 lb-in, S.F. 4.10
*Additional option to extend hopper36” taller to increase capacity from 175 to 357 cubic ft +$3,700.00
Out of stock
Rubber over Steel rollers with scalping plate for metering material.
Dimensions:
• 40’ long
• 13-8 Tall
• 48” wide
• 11’-7” discharge height
• 8’ load area
• 2’-6” top flat section.
Features:
• Auto-Oiler
• Adjustable material splitter (For metering lose material)
• Reversible Gearbox
• Pit plates included
It was used to feed a 300hp, model 4800 American Pulverizer ring mill. (also available with controls)
Out of stock
New in 2018, low hours (500) Spare parts still available. (1 year warranty available)*
1120CM 25hp 240v/480v 3ph granulator (Made In The USA)
• spare knives,
• 4 screens, 5/16“, 1/8”, 3/32“ & 1/16”
• Vacuum take-off bin. (all spare parts are readily available in the USA)
C1 New air separation system (Made In The USA)
• 1.3 sq. ft. of separation area
• Full dust hood
• 1hp TEFC 360/230/460 3ph electric motor
• Power station mounted on pedestal including all disconnects and motor controls(480V)
• 2 Stainless steel deck covers for the separation surface
• Filter with filter-box providing a clean air supply to the separating table
• Air conveyor system complete with material handling fan, 7.5hp 240/480v 3ph electric motor, cyclone with clean-out door, 4“steel conduit & flex conduit at joints. – The above is mounted on an aluminum diamond plate finish platform over a steel frame
Dust Collector
• 3hp single phase 220v dual bag dust collector
*Warranties on used equipment can be purchased for an additional fee.
Out of stock
Model MS120 BF VF
SerialM6355
New in 2018
Dimensions:
• Diameter: 12 inches
• Face Length: 48 inches
• Weight 1615kg
Magnetic Force:
• Approximately 5 times stronger than conventional rare earth drums
• Ideal for Removing: Various grades of stainless steel
• Magnetic Strength: Approx 50,000,000 Gauss sqd/cm
• Design: Continuous pole
Features:
• Unique Design: Attracts and holds weakly magnetic materials, including many grades of stainless steel
• Superior Design: Compared to belt over magnetic roller type separators, it prevents ferrous materials from being caught between the magnet and belting
• Integrated dust hood with vented top
Construction:
• Manufactured: In the UK
• Drum Width: 1200mm
• Includes: Base frame with guards, motor gearbox, and splitter/baffle
• Vibratory Feeder: included.
