• Model 144MCF572
• Sectional construction
• 3 ring sections (this model normally only has 2)
• Automatic pulse clean system
• Access ladder and service platform
• Steel support structure
Out of stock
Description:
• With hydraulic pushing ram
• 1,533 use hours
• Built in 2018
• Commissioned in 2019
Specs:
• Rotor speed: 63rpm
• Rotor diameter: 480mm
• Rotor blades: 59
• Static blades: 3
• Ram chamber: 815mm
• Discharge height: 675mm
• Screen diameter (holes): 40mm
• Motor power: 110kw (150HP)
• Hydraulic power: 5.5kw (7.5HP)
• Chamber size: 1,462mm x 1,204mm
• Overall dimension: 2,843mm x 3,044mm x 2,307mm
• Approximate weight: 11,000kg
Out of stock
Model SVE 800/ X2200
• New in 2018
• New Rings and Pins
• 300hp 480v
• Hinged Reject Chute
• Hydraulic Screen Cradle
• Mill is equipped with a fire suppression system
• Controls available*
*This was part of a larger system that included Infeed Pit conveyor, under Mill oscillator, exit conveyor Magnets, eddy current, etc. These additional items are also available.
CMIM Vertical Impact Mill Model V2000
• 200hp 3ph 480V electrical motor.
• Dims (inches): 101.5 x 153 x 134.5
• Hardened Impact Bars
• Ribbed Interchangeable Wear Plates
• Interchangeable screens
• Controls (VFD) included + Infeed conveyor
Applications:
• Pre-shredded Li-ion battery scrap
• Pre-shredded electric cables (copper and plastic)
• Pre-shredded electric cables (aluminium and plastic)
• Pre-shredded ASR
• Pre-shredded electronic scrap
• Pre-shredded Aluminium and copper radiators
• Pre-shredded Aluminium cans
The CMTM-1500 turbo mill is designed to grind rigid and semi-rigid materials into a fine particle size smaller than 1/16″ in diameter. It’s especially apt at processing hair wires and fine strand materials.
Turbomill:
• 200hp TEFC 360/230/460 3ph electric motor.
• Carbon steel plate body.
• Easily interchangeable steel wear-plates and beater knives.
• Clam-shell design for easy opening.
CMBL-4:
• 50hp blower W-VFD
• Cyclone
• Airlock
Controls Cabinet:
• 200 HP VFD for Turbo*
• 50 hp VFD for Blower*
• Motor starter for airlock
• 5hp VFD for infeed hopper. (not included in sale price, but available)
*VFD needed to properly operate. (included)
A blower, cyclone, and air-lock valve are required in order to pull the material thru the Turbo Mill. (Included)
$385K, turn key system, can demo anytime
Out of stock
SSI Shredder
Model Q100ED (63) Sealed chamber.
Newly rebuilt head with new knives (By SSI Technician in 2023)
• (2) 150 HP Motors
• Cutting Chamber Opening Size: 62″ x 63″
• 2.5″ Screen
• 17 Blades per Shaft
• 2 Hooks per Blade
• 2010 Model
• 3700 HRS (20 on new knives)
• Old knives are included and can be resurfaced.
• Hopper extension is available.
• Controls are included; it is operational and still powered up.
Conveyor with hood
• Kuhne Brand, Model: GBF 325 – 8.6 – 2
• 80” Wide
• 29’ long
• Integrated hood.
• The lower sheet metal guard plate is bent but still operational.
• Loaded on Truck
