Medical Waste Disposal & Recycling

Technology designed for the safest results

With years of experience in size reduction and product destruction, Cable Management is leading the way in innovative technologies and solutions for medical sharps and waste disposal and recycling.

Contact Us and discover why our equipment is the best for your medical sharps and waste disposal needs.


CMIM-1609 Impact Mill

Call for Price

CMIM-1609 Impact Mill

Designed to process:

  • Hard drives, small e-scrap, (Cell phones, memory, etc.)
  • Medical waste
  • Copper Bearing Steel Scrap

SYSTEM FEATURES:

  • Motor 5 to 7.5hp 3 phase electrical motor (available in single phase)
  • Belt Driven
  • Reverse Hopper for easy loading and material retention.
  • Weight: approximately 1500lbs
  • Standard box discharge. (Conveyor height discharge available)
  • Reversible impact bars for additional life.
  • High throughput, small footprint.
  • Replaceable impact bars, case liners, and screens.





CMTM-500 Turbo Mill

Call for Price

CMTM-500 Turbo Mill

Fine Hair Wires Solution.

  • Are copper fines getting thru your granulator screen with insulation still on the wire?
  • Are you having to run your material thru your system more than once to make sure it's clean?
  • Are you losing hair wires in your tailings?

A Turbo Mill is the only screen-less system that will take your copper fines and tumble them into little balls.

These little balls react just like the coarse copper on the separation tables removing the “clumpy” factor.

The extremely high speeds and rolling action removes any remaining insulation that may still be on your wires.

The material is vacuumed thru the drum horizontally and gets pulverized and rolled as it travels thru to the evacuation port.

The process is caused by multiple blunt edge blades that do not need a opposite cutting or “bed” knife. This results in a maintenance schedule that is less than 1/50 of a conventional Granulator.

CMTM-250 Turbo Mill

Call for Price

CMTM-250 Turbo Mill

Fine Hair Wires Solution.

  • Are copper fines getting thru your granulator screen with insulation still on the wire?
  • Are you having to run your material thru your system more than once to make sure it's clean?
  • Are you losing hair wires in your tailings?

A Turbo Mill is the only screen-less system that will take your copper fines and tumble them into little balls.

These little balls react just like the coarse copper on the separation tables removing the “clumpy” factor.

The extremely high speeds and rolling action removes any remaining insulation that may still be on your wires.

The material is vacuumed thru the drum horizontally and gets pulverized and rolled as it travels thru to the evacuation port.

The process is caused by multiple blunt edge blades that do not need a opposite cutting or “bed” knife. This results in a maintenance schedule that is less than 1/50 of a conventional Granulator.

CMTM-150 Turbo Mill

Call for Price

CMTM-150 Turbo Mill

The CMTM-150 turbo mill is designed to grind rigid and semi rigid
materials into a fine particle sizes smaller than 1/16″ in diameter.

  • Capacity of the machine is determined by the rigidity of the materials and particle size.
  • 10hp TEFC 360/230/460 3ph electric motor (15hp available for more throughput)
  • Carbon steel plate body.
  • Easily interchangeable steel wear plates and beater knives.
  • Dims: 46″x22″x22″
  • (Priced with 10hp option, throughput of up to 300lbs/hr)

NOTE: A blower, cyclone and air-lock valve are required in order to pull
the material thru the Turbo Mill.

OPTIONAL: The following options are available at an additional cost.

  • VFD (for speed control) $1,200
  • 15hp Motor *up to 450lbs/hr +$400

CMTM-1000 Turbo Mill

Call for Price

CMTM-1000 Turbo Mill

Fine Hair Wires Solution.
  • Are copper fines getting thru your granulator screen with insulation still on the wire?
  • Are you having to run your material thru your system more than once to make sure it's clean?
  • Are you losing hair wires in your tailings?

A Turbo Mill is the only screen-less system that will take your copper fines and tumble them into little balls.

These little balls react just like the coarse copper on the separation tables removing the “clumpy” factor.

The extremely high speeds and rolling action removes any remaining insulation that may still be on your wires.

The material is vacuumed thru the drum horizontally and gets pulverized and rolled as it travels thru to the evacuation port.

The process is caused by multiple blunt edge blades that do not need a opposite cutting or “bed” knife. This results in a maintenance schedule that is less than 1/50 of a conventional Granulator.

CMSHSS-25 Single Shaft Shredder

Call for Price

CMSHSS-25 Single Shaft Shredder

Scrap Metal Shredder With Hydraulic pushing Ram.

Specs:

  • Rotor Speed: 73rpm
  • Rotor Diameter: 220mm
  • Rotor Blades: 23
  • Static Blades: 4
  • Ram chamber: 500mm
  • Discharge height: 500mm
  • Screen Diameter (holes): 40mm
  • Motor power: 18.5kw (25hp)
  • Hydraulic Power: 1.5kw (2hp)
  • Chamber size: 600×510 (mm)
  • Overall dimension: 1850x1300x1700 (mm)
  • Weight 1700kg



CMIM-2416 Impact Mill

Call for Price

CMIM-2416 Impact Mill

Designed to process:

  • E-scrap
  • Small Appliances
  • Hand Tools (Drills, Saws etc.)
  • Ballast
  • Copper Bearing Steel Scrap
  • Copper & Aluminum Transformers
  • Brass Valves, Plumbing Fittings & Faucets
  • Motor Stators
  • Aluminum-copper Radiators with Ends
  • Copper, Brass, & Aluminum Lugs

SYSTEM FEATURES:

  • Motor 30hp 3 phase electrical motor
  • Belt Driven
  • Reverse Hopper for easy loading and material retention.
  • Weight: 3500lbs
  • Conveyor discharge height stand .
  • Reversible impact bars for additional life.
  • High throughput, small footprint.
  • Replaceable impact bars, case liners, and screens.

CMIM-1609 Impact Mill

Call for Price

CMIM-1609 Impact Mill

Designed to process:

  • Hard drives, small e-scrap, (Cell phones, memory, etc.)
  • Medical waste
  • Copper Bearing Steel Scrap

SYSTEM FEATURES:

  • Motor 5 to 7.5hp 3 phase electrical motor (available in single phase)
  • Belt Driven
  • Reverse Hopper for easy loading and material retention.
  • Weight: approximately 1500lbs
  • Standard box discharge. (Conveyor height discharge available)
  • Reversible impact bars for additional life.
  • High throughput, small footprint.
  • Replaceable impact bars, case liners, and screens.

CMBL-3 Material Handling Blower/Cyclone

Call for Price

CMBL-3 Material Handling Blower/Cyclone

15hp material handling fan with cyclone & Material handling pipe

(Made in the USA)

  • 1-air conveyor system complete with material handling fan and blower.
  • Heavy duty carbon steel blower with reinforced impeller.
  • 15hp 240/480v 3ph electric motor.
  • Cyclone with clean-out door.
  • 6″steel conduit & flex conduit at joints.

Hourly capacity depends on material density

The above can be mounted on an aluminum diamond plate finish platform over a steel frame with levelers or can be mounted to a floor level plate to save space.

CMBL-2 Material Handling Blower/Cyclone

Call for Price

CMBL-2 Material Handling Blower/Cyclone

10hp material handling fan with cyclone & Material handling pipe

(Made in the USA)

  • 1-air conveyor system complete with material handling fan and blower.
  • Heavy duty carbon steel blower with reinforced impeller.
  • 10hp 240/480v 3ph electric motor.
  • Cyclone with clean-out door.
  • 6″steel conduit & flex conduit at joints.

Hourly capacity depends on material density

The above can be mounted on an aluminum diamond plate finish platform over a steel frame with levelers or can be mounted to a floor level plate to save space.

CMBL-1 Material Handling Blower/Cyclone

Call for Price

CMBL-1 Material Handling Blower/Cyclone.

(Made in the USA)

  • 1-air conveyor system complete with material handling fan and blower.
  • Heavy duty carbon steel blower with reinforced impeller.
  • 7.5hp 240/480v 3ph electric motor.
  • Cyclone with clean-out door.
  • 3″steel conduit & flex conduit at joints.

Hourly capacity depends on material density

The above can be mounted on an aluminum diamond plate finish platform over a steel frame with levelers or can be mounted to a floor level plate to save space.

OPTIONAL:
Side mounted filter-head $1,323.00
